Apparel Processing Machine with Resin Spray
Product Details:
X
Product Description
Apparel Processing Machine with Resin Spray
Apparel Processing Machines with Resin Spray Attachment 'PR' Range & Low Spin Extract. Font loading, open pocket. For wrinkle-free spray treatment, Enzyme/Stone Washing, Dyeing & speciality Washes. 120, 240 & 360 kg. Capacity.
Digital Time & Temperature Control
A digital timer runs the process for the preset time & gives flash light signal at the end of each cycle. Another digital timer controls the low spin extract time. Auto digital temperature control. Individual controls for cylinder speed, water, steam & drain valve. Easy to operate
Simple, Efficient Inverter Drive
Single motor inverter drive gets all precision speeds, required for enzyme/stone washing, dyeing, turbo dyeing & other speciality washes. Low spin extract is affected by the same motor. The energy efficient drive reduces electric peak load demands.
Resin Mist Spray
High pressure 7 nozzles manifold atomize the resin into a mist spray for uniform absorption.
Technical Specification
| Model | Capacity dry wt. Per charge (1:10) | Cylinder Size / Volume | Wash Motor | Cylinder Speeds | Loading Door opening | Water connection/ consumption | Drain | Steam connection / consumption | Air connection / consumption | Dimensions WxDxH | Net. wt. / Crated wt. Crated size: WxDxH crated Volume | |
| Wash | Extract | |||||||||||
| PRS 120 | 120 kg | Ø 1350x850 / 1216 ltrs. | 5.5 kw | 15 to 50 RPM (Variable) | 160 RPM | Ø 800 | Ø50 (2'' BSP) / 1200 ltrs/ cycle | Ø 100 | Ø25 (1'' BSP) / 120 kg / hr | Ø15 (0.5'' BSP)/ 30 ltrs. /hr | 1550 x 1900 x 2000 | 1880 kg/ 2110 kg 1850 x 2200x 2300 (1 No.) 800 x 1400x 1500 (1 No.) 9.36 M3 + 1.68 M3 |
| PRS 240 | 240 kg | Ø 1600x1250 / 2410 ltrs. | 11 kw | 15 to 50 RPM (Variable) | 120 RPM | Ø 1000 | Ø50 (2'' BSP) / 2400 ltrs. / cycle | Ø 150 | Ø25 (1'' BSP) / 240 kg / hr | Ø15 (0.5'' BSP)/ 60 ltrs. /hr | 1800x 2400x 2150 | 3150 kg/ 3590 kg 2100 x 2700x 2450 (1 no.) 800x 1400x1500 (1 no.) 9.36M3 + 1.68 M3 |
Apparel Sampling machine with normal spin extract. 15 kg Capacity. PXS – Steam Heated PXE- Electric Heated
| PXRS 15 PXRE 15 | 15 Kg | Ø 720 x 380 / 154 ltrs | 2.2 kw | 15 to 50 RPM (Variable) | 500 RPM | Ø 500 | Ø20 (0.75'' BSP) / 150 Ltrs. / cycle | Ø75 | PXRS 30 Ø15 (0.5'' BSP) / 15 Kg/ hr | PXRE 30 6/ 12 kw | 950x 1000x 1480 | 760 kg/ 870 kg 1250x1300x1780 (1 No.) 800x1400x1500 (1 No.) 13.8M3 + 1.68 M3 |
